Advanced Guide to Custom Cooling Solutions for Ultimate Performance

For those who want the absolute best cooling performance and complete control over their PC's temperature, custom liquid cooling is the way to go. Custom cooling loops provide the highest level of cooling efficiency and allow users to create a personalized cooling system that not only performs but looks stunning. This section explores custom cooling systems, components required, and tips for building a custom loop.

Custom Cooling Components

A custom liquid cooling loop requires several components that allow you to build a unique setup tailored to your PC’s specific cooling needs. Here’s what you’ll need:

  1. Radiators: Radiators dissipate the heat absorbed by the coolant. Radiator size (120mm, 240mm, 360mm, etc.) and thickness determine the cooling capacity. Larger radiators are more effective and are often necessary for overclocked systems.
    • Top Radiators: EKWB CoolStream PE 360, Corsair Hydro X Series XR5, Alphacool NexXxoS XT45.
  2. Water Blocks: Water blocks are attached to components like the CPU and GPU, allowing coolant to absorb heat. CPU water blocks and GPU water blocks are available for major brands, and some blocks even feature RGB lighting.
    • Popular Water Blocks: EKWB Quantum Velocity (CPU), Corsair Hydro X Series XG7 (GPU), Phanteks Glacier C360i (CPU).
  3. Reservoirs: Reservoirs hold the coolant and are often combined with a pump in custom cooling loops. They come in various sizes, allowing for more liquid storage and aesthetic customization.
    • Recommended Reservoirs: EKWB X3 Reservoir, Thermaltake Pacific PR22-D5, Corsair Hydro X Series XD5.
  4. Pumps: The pump circulates the coolant throughout the system. A powerful pump is essential for long loops with multiple radiators or water blocks.
    • Best Pumps: EKWB D5 PWM, Corsair Hydro X XD3, Alphacool VPP655.
  5. Tubing: Tubing carries the coolant from component to component. Soft tubing is more flexible and easier to work with, while hard tubing looks cleaner and offers a high-end aesthetic.
    • Top Tubing Choices: PrimoChill PrimoFlex (soft tubing), EKWB ZMT Tubing, Thermaltake V-Tubler PETG (hard tubing).
  6. Coolant: Coolant absorbs and carries heat throughout the system. There are various coolants available in different colors, and some come with anti-corrosive properties to protect the loop.
    • Recommended Coolants: EK CryoFuel, Corsair Hydro X, Mayhems Pastel.

How to Build a Custom Liquid Cooling Loop

Building a custom cooling loop requires careful planning, the right tools, and some hands-on work. Here’s a general step-by-step guide:

  1. Plan Your Loop Layout: Sketch out where each component will go, considering the location of the pump, reservoir, radiators, and tubing runs. Ensure you have enough space in your case for all components.
  2. Install the Water Blocks: Attach the CPU and GPU water blocks according to the instructions provided. Use thermal paste for the CPU block to ensure proper heat transfer.
  3. Mount the Radiator(s): Install radiators in your chosen locations (typically the top, front, or rear of the case). Ensure they have sufficient airflow.
  4. Place the Reservoir and Pump: Mount the reservoir and pump where they are easily accessible for filling and maintenance.
  5. Connect the Tubing: Measure and cut tubing sections to fit between components. If using hard tubing, you’ll need a bending kit to create custom bends. Attach tubing securely with fittings to prevent leaks.
  6. Fill and Test the Loop: Add coolant to the reservoir and power the pump using a separate power supply to test for leaks without powering on the rest of the system. Let the pump run for at least 24 hours to ensure there are no leaks.
  7. Bleed the System: Remove any air bubbles from the system by gently tilting the case to allow trapped air to escape. This process prevents air pockets, which can reduce cooling efficiency.
  8. Monitor Temperatures: Once the loop is operational, use monitoring software to keep track of component temperatures and pump performance. This helps identify any issues early and ensures the cooling system is working as expected.

Best Practices and Tips for Custom Cooling

Building a custom loop can be challenging, but with these tips, you can ensure a smooth process and optimal performance:

  1. Invest in Quality Fittings: Fittings connect tubing to components, and high-quality fittings help prevent leaks. Brands like EKWB, Bitspower, and Thermaltake offer reliable options.
  2. Use Non-Conductive Coolant: For added safety, opt for non-conductive coolants that won’t damage components if a leak occurs. Anti-corrosive and anti-bacterial additives are also beneficial for loop maintenance.
  3. Consider Fan Placement and Radiator Thickness: Thicker radiators with more surface area and push-pull fan setups (fans on both sides of the radiator) provide better cooling performance.
  4. Regular Maintenance: Custom loops require maintenance every 6 to 12 months to ensure performance and longevity. Flush the system, clean the water blocks, and replace the coolant to prevent buildup.
  5. Calculate Cooling Needs Based on TDP: Calculate the total thermal design power (TDP) of your components to ensure your cooling system can handle the heat load. This is especially important for overclocked or multi-GPU setups.
  6. Double-Check for Leaks: Leaks are the biggest risk with custom loops, so thoroughly test your loop before powering up your computer.

Best Liquid Coolers and Air Coolers for Different Needs (Expanded List)

Top High-Performance AIO Coolers for Overclocked Systems

  1. EKWB EK-AIO Elite 360 D-RGB - High cooling capacity with a 360mm radiator.
  2. Thermaltake Floe RC 360 - AIO cooler with memory cooling and 360mm radiator.
  3. Corsair H170i Elite Capellix - Large 420mm radiator for extreme cooling performance.
  4. Cooler Master MasterLiquid ML360 - Strong cooling with addressable RGB fans.
  5. DeepCool Castle 360EX - Excellent cooling performance and unique aesthetics.

Additional Air Coolers for Specific Builds

  1. Scythe Fuma 2 - Dual-tower design, efficient and quiet, great for mid-range PCs.
  2. Thermalright Le Grand Macho RT - Silent with excellent cooling for larger cases.
  3. Zalman CNPS20X - Advanced air cooling, dual tower with RGB.
  4. Noctua NH-L12S - Low-profile cooler, ideal for small form factor builds.
  5. SilverStone AR07 - Affordable with good performance for everyday builds.

Specialized Case Fans for Maximum Airflow and Aesthetics

  1. Lian Li Uni Fan SL120 - Daisy-chained RGB fans for easy setup.
  2. Thermaltake ToughFan 12 - High static pressure, ideal for radiators.
  3. Phanteks T30-120 - 30mm thick fan for maximum airflow.
  4. Antec Prizm 120 ARGB - RGB lighting with good airflow.
  5. Corsair QL120 RGB - Quad lighting zones for high customizability.

Top Radiators for Custom Loops

  1. Hardware Labs Black Ice Nemesis 360GTS - Slim profile with excellent performance.
  2. Alphacool NexXxoS Monsta 420 - Thick radiator for extreme cooling capacity.
  3. XSPC RX V3 240mm - High-performance radiator, great for smaller setups.
  4. EK-CoolStream SE 280 - Compact but effective, perfect for tighter cases.
  5. Corsair Hydro X Series XR7 480mm - Massive cooling potential, ideal for enthusiasts.

Best Pumps for Custom Liquid Cooling

  1. Aquacomputer D5 Next - High-performance with built-in display.
  2. EKWB EK-XTOP DDC 3.2 PWM Elite - Compact and powerful for smaller loops.
  3. Thermaltake Pacific PR15-D5 - Integrated pump/reservoir combo for easy setup.
  4. Alphacool VPP755 - Adjustable speed with high durability.
  5. Phanteks Glacier D140 - Quiet and efficient, great for custom loops.

Advanced Cooling Accessories and Add-ons

Beyond the essentials, several accessories can enhance the performance, aesthetics, and ease of use of your cooling system.

Fan Controllers and RGB Hubs

  1. Corsair iCUE Commander PRO - Controls fan speed and RGB lighting with iCUE software.
  2. NZXT RGB & Fan Controller - Compact with CAM software integration.
  3. Thermaltake TT Sync Controller - Syncs RGB lighting across multiple devices.

Temperature Sensors and Monitoring

  1. Aqua Computer Dr. Drop - Leak tester to ensure loop safety before operation.
  2. EK-Loop Connect - Fan and temperature controller with comprehensive monitoring.
  3. Phobya Inline Temperature Sensor - Monitors coolant temperature in custom loops.

RGB LED Lighting Kits for Aesthetic Builds

  1. Corsair Lighting Node PRO - Customizable RGB lighting for advanced lighting effects.
  2. NZXT Hue 2 RGB Lighting Kit - Adds vibrant lighting to your system.
  3. Phanteks Neon Digital-RGB LED Strip - Flexible and vibrant lighting for custom loops.

Thermal Paste Options for Enhanced Cooling Efficiency

  1. Arctic MX-4 - High-performance and long-lasting, ideal for CPU and GPU.
  2. Thermal Grizzly Kryonaut - Excellent thermal conductivity, great for overclocking.
  3. Noctua NT-H1 - Reliable and easy to apply, suitable for air and liquid coolers.

Common Cooling System Mistakes to Avoid

  1. Using Too Much Thermal Paste: Excess thermal paste can cause overheating rather than preventing it. Use a small, pea-sized amount for best results.
  2. Incorrect Fan Orientation: Place fans for optimized airflow, with a balance of intake and exhaust for ideal cooling.
  3. Skipping Leak Testing: Always test custom loops for leaks before powering the system, as this prevents costly component damage.

Conclusion: Picking the Best Cooling Solution for Your PC

Effective cooling is a key factor in maintaining optimal performance, especially for high-powered gaming PCs, workstations, and overclocked systems. Whether you choose an air cooler, an AIO, or go all-out with a custom liquid cooling loop, your cooling solution can enhance your system’s performance, longevity, and even its aesthetic appeal. With this guide, you’re equipped to find the best cooling solution tailored to your build and keep your system running cool and efficiently for years to come.
